APPLICATION

1 actuator for sliding gates, series BULL10M, BULL15M and BULL20M

CONTROL UNIT POWER SUPPLY

230 Vac – 50/60 Hz

MOTORS POWER SUPPLY

230 Vac

MAIN FUNCTIONS

Integrated LCD display | Integrated 433.92 MHz 64-code radio receiver with 3 encoding systems (Advanced Rolling Code, Rolling Code, Fixed Code) | Removable terminal boards | Automatic, semi-automatic and deadman’s logic | Encoder input to detect obstacles | Motor limit switch inputs | Open, close, pedestrian, step by step and stop inputs | Photocell input (PHOT O) programmable as active in opening-closing and in closing phases | Photocell input (PHOT C) programmable as active in opening-closing phases | Input for N.C or 8K2 sensitive edge | Output for configuration as gate open indicator, service light, or second radio channel | Photocell testing output | Autosetting of operating parameters | Electronic motor torque adjustment | Adjustable slow-down systems | Electronic braking guarantees a precise stop even with heavy doors | Advantouch system to configure parameters and manage radio transmitters | Number of maneuvers | Programming access password | Maintenance warningPower supply230 Vac (50-60Hz)Motor supply230 VacMax absorbed current2.9 AMaximum thrust1667 NOpening speed10.5 m/minDuty cycle40%Protection levelIP44Built-in control unitIntegrated receiverEncoderVirtual encoderMagnetic limit switchesPinion for rackM4 Z18Operating temperature-20°C /+50°CLubricationGREASEMaximum gate weight2000 kgWeight21.1 kgN. motors per pallet20
