Conductor

Material

CCA (Copper)

Diameter

0.57 mm ± 0.01 mm (0.0224"±0.0004")

Wire Gauge

23AWG

Insulation

Material

HDPE

Thickness

0.21 mm (0.0083")

Diameter

1.02 mm±0.1 mm (0.0402"±0.004")

Color

Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown

Rip Cord

Material

Polyester

Specification

500D

Separator

Material

PE

Specification

Translucent 4.5 mm × 0.4 mm (0.1772"±0.0157")

Sheath

Material

PVC

Min. Average Thickness

0.5 mm (0.0197")

Diameter

6.5 mm±0.3 mm (0.2559"±0.0118")

Color

Orange

Electrical

Dielectric Strength

No breakdown with 1kV DC for 1 min

Max. DC Resistance of a Single Conductor

11.5Ω/100 m

Max. DC Resistance Unbalance

2% (pair intra), 4% (pairs inter)

Min. Insulation Resistance

5000MΩ·km

Environmental

Color Migration Resistance of Insulation

No migration

Heat Shock Test

No cracking after the test

Installation Temperature

0°C to +50°C (32°F to 122°F)

Low Temperature Bending Test

No cracking after the test

Operation Temperature

–20°C to +60°C (–4°F to 140°F)

Sheath Tensile Strength and Elongation at Break after Aging

≥12.5 MPa, ≥100%

Shrinkage of Insulation

≤5%

Storage Temperature and Humidity

–10°C to +40°C (14°F to 104°F), <60% (RH)

Mechanical

Conductor Elongation at Break

≥10%

Elongation at Break

Sheath≥150%, insulation≥300%

Installation Bending Radius

>8 times of outer cable diameter

Tensile Strength

Sheath≥13.5 MPa, insulation≥16 MPa

Packaging

Cable Length

100.0 m (328.08 ft)±1 m (3.28 ft)

Gross Weight

3.5 kg±0.3 kg (7.72 lb±0.66 lb)

Inner Carton Dimensions

286 mm × 119 mm × 289 mm (11.26" × 4.69" × 11.38")(L × W × H)

Net Weight

3.2 kg±0.3 kg (7.05 lb±0.66 lb)

Packaging Dimensions

595 mm × 310 mm × 270 mm (23.43" × 12.20" × 10.62") (L × W × H)

Packaging Method

100 m/carton, 4 inner cartons in one package

Security

Vertical Fire Propagation Test

Comply with IEC 60332-1-2

Transmission

Characteristic Impedance

100Ω ± 15Ω

Max. Attenuation

34.8 dB/100 m @250 MHz

Near End Cross Talk

≥39.30 dB/100 m @250 MHz

Return Loss

≥17.3 dB/100 m @250 MHz

Compliance

Executive Standards

Q/DXJ 067-2019

Certification

Certification

CPR Eca

Flame-retardant Standard

Compliance Standard

EN 50575 Eca
