YLI Electronic Electric Strike With Long Faceplate
Electric strikes come in many varieties.YS-132NO/NC-S is the electric strike with a long faceplate and signal output. It has two modes: A fail-safe electric strike needs power to keep it locked. A fail-secure electric strike stays locked even without power.
Single Door Magnetic Lock The L Bracket The U Bracket European Type Heavy Duty Electric Strike with Signal Door Release Button (Stainless Steel) Door Release Button In Wall Plastic Box Infrared sensor button (stainless steel) Emergency key switch (Same Key) (stainless steel) Remote Control for Access Control Transmitter Touch Button Resettable emergency call point (single pole) (green) Power Supply Uninterrupted power supply Interlock module of two doors Access control externally-connected module
| Product Parameter | Parameter Description |
| Lock Size | 250Lx25Wx31H(mm) |
| Strike Structure | Stainless Steel |
| Holding Force | 500kg |
| Voltage | DC12V (Need Order DC24V) |
| Current | 200mA(YS-132NO-S);200mA(YS-132NC-S) |
| Feature | Fail Secure(YS-132NO-S); Fail Safe(YS-132NC-S) |
| Signal Output | Lock Status OutputNO/NC/COM |
| Suitable For: | Wooden Door, Metal Door, PVC Door |
| Surface Temperature | Within +20℃ |
| Suitable Temperature | -10~+55℃(14-131F) |
| Operating Humidity | 0～90%(non-condensing) |
| Faceplate Housing | Painted Steel |
| Function | Built-out MOV |
| Optional Accessories | YS-308 |
| Weight | 0.4kg |
